Key Features
Power Capacity: 10kVA / 10kW
Topology: Double-Conversion On-Line for seamless power protection
Wave Type: Pure sine wave output for sensitive electronics
Transfer Time: 0ms (continuous power conversion)
Efficiency: Operates at 94% efficiency at full load
Extended Runtime: Supports up to 4 external battery packs for prolonged backup
Battery & Protection
Battery Type: Sealed lead-acid, 240V
Recharge Time: ~5 hours
Battery Life: 3–5 years
Surge Protection: Shields devices from power spikes
Cold Start Capability: Allows startup without mains power
Battery Failure Notification: Alerts users to potential battery issues
Connectivity & Management
Outlets: Hard wire 3-wire (1P + N + E)
Input Connection: Hard wire 3-wire (1P + N + E)
Communication Ports: USB & RS-232
Intelligent Card Slot: Supports optional management cards
LCD Display: Multi-function graphic panel for real-time UPS status
Configurable Output Voltage: Adjustable to 220V, 230V, or 240V
Physical & Environmental Specs
Form Factor: Rackmount (5U)
Dimensions: 61.5 cm (D) × 43.8 cm (W) × 21.95 cm (H)
Weight: ~78 kg
Operating Temperature: 0–40°C
Humidity: 0–95% non-condensing
Noise Level: 58 dBA
This UPS is ideal for data centers, enterprise IT setups, VoIP systems, and critical infrastructure, ensuring uninterrupted operation during power disturbances.
